Công ty chúng tôi là đại diện phân phối BAYKEE tại Việt Nam:
HW | ||||||
MODEL | HW-1K | HW-2K | HW-3K | |||
Capacity | 1kVA | 2kVA | 3kVA | |||
Power Watt | 0.8kW | 1.6kW | 2.4kW | |||
Working Principle | Low Frequency Transformer Based True On Line-Double Conversion | |||||
RECTIFIER (INPUT) | ||||||
Phase | Single Phase | |||||
Input Voltage Range | 220VAC (230VAC or 240VAC)±25% , 1P+N+PE | |||||
Input Frequency Range | 50Hz±10% / 60Hz±10% (Selectable) | |||||
Output Ripple | <2% | |||||
Soft Start | 0~100% 5sec | |||||
CHARGING | ||||||
Charging Mode | Constant current, then constant voltage, and charge with temperature compensation | |||||
Float Charging Voltage | 55VDC | |||||
Equalized Charging Voltage | 56.8VDC | |||||
Temp. Compensated Voltage | -3mV/℃/cell | |||||
Charging Current | 5-10A | |||||
BATTERY | ||||||
Type | VRLA/AGM/Gel, optional Lithium Battery | |||||
Battery Capacity | 7~200AH settable ( Configurate Battery Capacity according to Back-up Time ) | |||||
Quantity | 4units 12V or 24units 2V batteries ( Battery Voltage 48VDC) | |||||
Temperature | 20ºC~25ºC (For Maximum Efficiency) | |||||
INVERTER (OUTPUT) | ||||||
Phase | Single Phase | |||||
Nominal Voltage | 220VAC (230VAC or 240VAC), 1P + N | |||||
Output Voltage Regulated Accuracy | ±1 %( Stable load), ±3%( fluctuant load) | |||||
Output Frequency Range | 50Hz 60Hz<±0.5% ( Asynchronous ) | |||||
Crest Factor | > 3:1 | |||||
Output Total Harmonic Distortion (THD) | Pure Sine Wave, Linear Load < 3%, Non-Linear Load<5% | |||||
Dynamic Characteristics | Instant voltage<±5% ( from 0 to100% ), Instant recover time<10ms | |||||
Overload Capacity | At 115% load, normal work, At 125% load 10 min, At 150% load 1min | |||||
Inverter Efficiency | >93% ( full load ) | |||||
BYPASS | ||||||
Phase | Single Phase ( P+N ) | |||||
Nominal Voltage | 220VAC (230VAC or 240VAC) | |||||
Transfer Time | 0ms( adopt static switch ) | |||||
PROTECTION FUNCTION | ||||||
Input Protection | Input voltage, frequency over limited protection | |||||
Output Protection | Over current, short circuit, over voltage, low voltage | |||||
Battery Protection | Over charge, over-discharge protection | |||||
Temperature Protection | Environment over temperature protection, inverter over temperature protection | |||||
Hardware Fault Protection | Assistant power abnormal, breaker cut off, breaker overload, power devices over current/over voltage etc. protection | |||||
GENERAL SYSTEM PARAMETERS | ||||||
Working Environment | Temp: -25~55ºC, relative humidity: 30%~90%, Altitude<2000m ( 1% decrease against 100 meters’ rise, Max. altitude 4000m ) | |||||
Cooling Method | COMPULSIVE VENTILATION | |||||
Communication Interface | RS232/ RS485, optional dry contact, SNMP card ( for remote control via internet ) | |||||
Auto-surge Capacity | 10/700μS, 5KV; 8/20μS, 20KA | |||||
Protection Level | IP43 | |||||
Safety Performance | Vin-n Vout-n 2000Vac, creepage<10mA , insulating resistance>2MΩ(500VDC) | |||||
Noise (dB) | 45~50 | |||||
Dimension (W*D*H) mm | 890*640*1250 (Max. built-in 8PCS12V100Ah Batteries | |||||
Weight (Kg) | 105 | 115 | 135 | |||
※100V-110V-120V Version is available |
